Technical Specification For S0

Mic Inputs Audio Specification

Input Impedance:
> 1k5Ω electronically balanced

Input Gain Range:
Preset pot +24dB to +67dB ref -50dBu

TRIM pot ± 15dB

Frequency Response:
40Hz to 20kHz –1dB

+0dB

Mic input E.I.N.:
-130dB with 150Ω source

Phantom Power:
+48V to each mic input (SCi selectable)

Common Mode Rejection Ratio:
> 60dB typically

Pan Range:
Off/-3dB Centre/Off

Stereo Line Inputs Audio Specification

Input Impedance:
> 20kΩ electronically unbalanced

Input Gain Range:
+10dB ref 0dBu at PGM output

TRIM pot ± 15dB

Frequency Response:
20Hz to 20kHz –0.5dB

+0dB

Noise (20Hz-20kHz):
-92dBu ref 0dB (fader down

no routing)

Total Harmonic Distortion:
0.015% at 1kHz

0.015% at 10kHz ref +8dBu

Balance Range:
± 6dB

Outputs Audio Specification

Output Impedance:
PGM output: < 50Ω electronically balanced

REC output: < 75Ω unbalanced Monitor output: < 75Ω unbalanced

Headphone output load: > 16Ω

recommended 250Ω

Maximum Output:
PGM output: +26dBu balancedREC output: Level:+16dBu unbalanced

Input & Output Connections

Audio Inputs:
4 x Microphone XLR-3 pin sockets

12 x Pair stereo line RCA phono sockets

1 x Pair stereo aux RCA phono sockets

1 x Stereo aux 3.5mm jack socket

Audio Outputs:

PGM:
2 x XLR-3 pin plug (balanced)

REC:
1 x Stereo pair RCA phono sockets

Monitor Inputs:
1 x Stereo pair RCA phono sockets

Monitor Outputs:
5 x 6.35mm (1/4”) stereo jack sockets

(2 x presenter

2 x guest

1 x loudspeaker)

Remote Outputs:
9 x 6.35mm (1/4”) stereo jack sockets (one per channel)

1 x 6.35mm (1/4”) stereo jack socket for light control

Telephone:
2 x RJ11 6/4 (1 x line

1 x handset)

USB Audio:
1 x Type-B receptacle

USB Serial:
1 x Type-B receptacle

Mains Input:
Filtered IEC

continuously rated 85-264VAC

47-63Hz

45w nominal

50w peak

Fuse Rating:
Anti-surge fuse 2A 20 x 5mm

Equipment Type

S0:
S0 radio broadcast mixer

Physical Specification

Dimensions (Raw):
48.3cm (W) x 35.6cm (D) x 12.5cm (H)

19" (W) x 14" (D) x 4.9" (H)

Dimensions (Boxed):
67cm (W) x 44cm (D) x 25cm (H)

26.4" (W) x 17.3" (D) x 9.84" (H)

Cut-Out Dimensions:
44cm (W) x 34.7cm (D)

17.32" (W) x 13.66" (D)

Weight:
Nett: 8.5kg Gross: 10.12kg

Nett: 18.7lb Gross: 22.26lb
