RVR TEX3003TFT – 3000W Compact FM Broadcast Transmitter

Product overview

The RVR TEX3003TFT Transmitter is a compact 3000W FM broadcast transmitter designed for high-reliability main and backup installations. It combines a broadband FM exciter, RF amplification and control in a single rackmount chassis to minimise footprint and installation time. Optimised for continuous duty service, it delivers clean modulation and stable output across the FM band. Ideal for medium to large broadcasters, it integrates easily into existing FM transmitter systems while maintaining low operating costs.

Key features

• 3000W FM output power in a compact rackmount form factor
• Integrated FM exciter and high-efficiency RF amplifier section
• Wideband FM Band II coverage for 87–108MHz operation
• Advanced protection for VSWR, over-temperature and overdrive
• Front-panel TFT display for status, metering and configuration
• Remote control and telemetry via Ethernet, SNMP or GPIO interfaces
• High-efficiency power supply to reduce heat and energy consumption
• Modular internal layout for easier servicing and maintenance

Connectivity and I/O

The RVR TEX3003TFT Transmitter offers balanced audio inputs, composite MPX input and, where configured, digital audio interfaces. RF output is provided on a high-power 50Ω connector suitable for transmission lines to the antenna system. Rear-panel terminations support mains AC input, remote control ports and telemetry outputs for integration into station monitoring networks.

In operation

In daily use, the transmitter delivers stable 3000W RF power with intuitive front-panel control and clear status indications for engineering staff. Remote access allows technical teams to monitor operating parameters and alarms from the control room or NOC, simplifying site management. Its efficient RF and power supply design helps maintain performance in demanding environments, making it suitable for primary, regional or high-reliability backup roles.
