The Sonifex RB-AES4B3 is a passive, quad “one-to-three” splitter housed in a 19” rack.

Sonifex RB-AES4B3

In stock

Original price was: $ 862.46.Current price is: $ 816.77.
Add to Cart
Weight 1.4 kg
Dimensions 23 × 59 × 7 cm
-5%
The Sonifex RB-AES4X3 is a passive, quad “one-to-three” splitter housed in a 19” rack.

Sonifex RB-AES4x3

In stock

Original price was: $ 862.46.Current price is: $ 816.77.
Add to Cart
Weight 1.4 kg
Dimensions 23 × 59 × 7 cm
-5%
The Sonifex RB-PLI6 is a  dual balanced converter that allows the user to convert two independent stereo inputs to two fully buffered mono outputs.

Sonifex RB-PLI6

In stock

Original price was: $ 868.17.Current price is: $ 822.48.
Add to Cart
Weight 1.5 kg
Dimensions 21 × 36 × 6 cm
-5%
The Sonifex RB-DAC1 Digital to Analog Converter is a 1 RU rackmount unit, which produces a stereo balanced XLR or unbalanced phono output.

Sonifex RB-DAC1

In stock

Original price was: $ 879.60.Current price is: $ 833.90.
Add to Cart
Weight 2 kg
Dimensions 11 × 48 × 5 cm
-5%
The Sonifex RB-DDA6A-2P digital distribution amplifier is used for distributing digital audio data in AES/EBU format, repeating both the audio data and the status.

Sonifex RB-DDA6A-2P

In stock

Original price was: $ 885.31.Current price is: $ 839.62.
Add to Cart
Weight 2 kg
Dimensions 23 × 59 × 7 cm
-5%
The Sonifex RB-DA4x5 is a dual balanced converter that allows the user to convert two independent stereo inputs to two fully buffered mono outputs.

Sonifex RB-DA4x5

In stock

Original price was: $ 891.02.Current price is: $ 845.33.
Add to Cart
Weight 2.2 kg
Dimensions 28 × 59 × 11 cm
-6%
The Sonifex RB-MSP6 is a 1U rack-mount phantom power supply, designed to be used in conjunction with up to six RB-MS4X3's, providing mains input redundancy to ensure the target microphones remain powered in the event of a single mains failure.

Sonifex RB-MSP6

In stock

Original price was: $ 931.00.Current price is: $ 879.60.
Add to Cart
Weight 1.5 kg
Dimensions 21 × 36 × 6 cm
-5%
The Sonifex RM-MC1L is a high-quality 1U rackmount microphone and line-level monitor unit, designed for broadcast, studio, and live sound applications.

Sonifex RM-MC1L

In stock

Original price was: $ 942.43.Current price is: $ 891.02.
Add to Cart
-5%
The Sonifex PS-PLAY is a high-performance multi-format audio player, designed for professional broadcast, studio, and AV applications.

Sonifex PS-PLAY

In stock

Original price was: $ 988.12.Current price is: $ 936.71.
Add to Cart
Weight 1.7 kg
Dimensions 38 × 30 × 6 cm
video

0
Product can be split into multiple boxes

0
Ship Separately

0
specification

Technical Specification For PS-PLAY

Analogue Outputs:
2 x XLR 3 pin (balanced)( L&R)


2 x RCA phono (unbalanced)( L&R)


1 x ¼ inch (6.35mm) stereo jack headphone socket

Analogue Max Output Level:
18dBu XLR balanced


8dBu RCA phono unbalanced

Analogue Balanced Output Impedance:
<50Ω

Analogue Unbalanced Output Impedance:
<75Ω

Analogue Output SNR:
94dB

Frequency Response:
20Hz – 20kHz using MP3 at sample rate of 192kbps and above

Output THD:
0.03% Relative

Interchannel Isolation (Cross Talk):
80dB (Ref FSD)

Analogue Output Gain Range:
-60dB to 18dB via front panel control knob

,

or optional IR controller

Digital Outputs:
1 x AES/EBU XLR 3 pin female


1 x S/PDIF RCA phono


1 x S/PDIF RCA phono

Headphones Output:
Drives 150mW into 32ohm to 600ohm stereo headphones

USB Port:
1 x USB A socket

GPOs (General Purpose Outputs):
2 x switchable relay contacts (simultaneously switched) controlled from PS-SEND

Serial Port:
1 x 9 way D-type socket

,

used to send control commands and update firmware

Ethernet Port:
1 x RJ45 socket. Remote control commands can be sent via TCP or UDP as well as firmware updates.

IR Remote Receiver:
Remote commands can be sent using optional remote control via built in IR sensor

Mains Input:
Filtered IEC

,

85 – 264VAC

,

47 – 63 Hz

,

10W max

Fuse Rating:
Anti-surge fuse 1A 20 x 5mm

Audio Codec Specifications Decoder
G.711 (U Law/A Law 8kHz to 48kHz sampling rate)


WAV (IMA ADPCM+ 16bit PCM uncompressed: 8kHz to 48kHz)


MP3 Layer 1 (32

,

44.1 and 48kHz

,

CBR +VBR +ABR)


MP3 Layer 2 (16

,

22.05 and 24kHz

,

CBR +VBR +ABR)


AAC+ (HE-AAC v2 Level 3

,

incl.SBR and PS)


Ogg Vorbis (floor 1)

Supported Network Transport Protocols
RTP – UDP


HTTP – TCP


Raw UDP


Raw TCP


SNMP – traps for remote management


DHCP

,

BOOTP

,

IPZator or AUTOIP – Dynamic IP address resolution


SonicIP IP Address readout

Physical Specification
Dimensions (Raw):    22cm (W) x 13.7cm (D) x 4.3cm (H)


8.67” (W) x 5.39” (D) x 1.7” (H)


Dimensions (Boxed): 34cm (W) x 27cm (D) x 6cm (H)


13.4” (W) x 10.6” (D) x 2.4” (H)


Weight:                          Nett: 0.84kg Gross: 1.64kg


Nett: 1.85lbs Gross: 3.6lbs
Color

Black
features

IP to audio streamer.
Built-in web server for configuration.
Balanced & unbalanced analogue audio outputs.
AES/EBU

,

S/PDIF and TOSlink digital audio outputs.
Front panel headphone monitor with local & remote volume control.
USB port acts as an audio source.
Can decode from a multitude of services

,

e.g. Shoutcast

,

Icecast.
2 x GPO relays controlled remotely from a PS-SEND.
Sale
The Sonifex RM-CA2 Confidence Monitor is a 1 RU rackmount unit offering quality loudspeaker monitoring and two-channel metering of two stereo analog audio sources.

Sonifex RM-CA2

In stock

Original price was: $ 1,393.65.Current price is: $ 1,319.40.
Select options
Sale
The Sonifex HY-03 analogue telephone hybrid is the replacement for the HY-02, which for many years has set the standard as an excellent value, high quality telephone hybrid.

Sonifex HY-03

In stock

Original price was: $ 1,153.76.Current price is: $ 1,090.93.
Select options
Weight 2 kg
Dimensions 18 × 22 × 5 cm
-4%
The Sonifex RB-DHD6 Headphone Amplifier receives a digital input signal, as either AES/EBU or S/PDIF and converts it to 6 individual headphone outputs.

Sonifex RB-DHD6

In stock

Original price was: $ 1,016.68.Current price is: $ 970.98.
Add to Cart
Weight 2.2 kg
Dimensions 23 × 59 × 7 cm
-6%
The Sonifex PS-PLAYS is a professional-grade multi-format audio player designed for broadcast studios, live production, and AV installations.

Sonifex PS-PLAYS

In stock

Original price was: $ 1,028.10.Current price is: $ 970.98.
Add to Cart
-5%
The Sonifex RM-MC4L has four stereo balanced analogue inputs with a single stereo balanced output, all using XLR connectors.

Sonifex RM-MC4L

In stock

Original price was: $ 1,039.52.Current price is: $ 982.41.
Add to Cart
Weight 1.9 kg
Dimensions 23 × 59 × 7 cm
Sale
The Sonifex PS-AMP is a freestanding unit which converts an IP audio stream directly to speaker outputs.

Sonifex PS-AMP

In stock

Original price was: $ 1,045.24.Current price is: $ 993.83.
Select options
Weight 1.9 kg
Dimensions 27 × 59 × 7 cm
