Mic Preamp Connector
XLR Floating balanced

Pin 2 Hot

Mic Preamp Input Impedance
~4.2kΩ

Mic Preamp gain
0dB to +60dB

Mic Preamp Phantom Power
+48VDC

applied to XLR pins 2 and 3 through 6.81kΩ resistors

CMRR
>40dB

typically 55dB

Mic Preamp max input level
0.2Vrms

Gain = 30dB

Mic Preamp Equivalent Input Noise (EIN)
-125dBu

22Hz-22kHz

150Ω source impedance

Input Connectors
(line) Floating balanced

TIP Hot

Input Impedance
(line) 10kΩ unbalanced

20kΩ balanced

Max Input
(line) >+21dBu

balanced or unbalanced

Input Gain Range
(line) -15dB to +45 dB

Insert Connector
1/4" TRS: Normalled; tip is Send

ring is Return

Insert Impedance
>5kΩ (ring-return); 100Ω (tip-send)

Insert Max Level
>+21dBu; >+20dBm (600Ω load-tip)

Insert Noise
<-84dBu

unweighted (20Hz-20kHz); LINE GAIN Control set to 0dB

Insert Distortion
<0.01% THD

20Hz-20kHz

+10dBu

Output Connectors
1/4" Balanced/Unbalanced TRS Connectors

Output Impedance
100Ω unbalanced

200Ω balanced

Max Output
>+21dBu

>+20dBm (600Ω load)

Gain Adjustment Range
-30dB to +10dB

Noise
<-80dBu unweighted (20Hz-20kHz); Both Gain Controls set for 0dB

all processing controls OFF

Frequency Response
20Hz to 20kHz

+0.5

-0.5dB

THD
<0.08%THD

20Hz-20kHz

+10dBu

all Processing Controls OFF

Compressor Threshold Range
-40dBu to +20dBu

Compressor Threshold Characteristic
OverEasy®

Compressor Ratio
>4:1 For input levels beyond 20dB above threshold

Max Compression
30dB

Compressor Attack Time
Program-Dependent; >1s for small level increases

down to 10ms for larage increases

Compressor Release Time
Program-Dependent; adjustable between approximately 1dB/sec and 75dB/sec

Compressor Distortion
Typically <0.05%THD

20Hz-20kHz

15dB G/R

+10dBu Output

DENSITY @ 0

IMD
SMPTE: <0.05%; 60Hz/7kHz 4:1

15dB G/R

+10dBu Output Level

DENSITY @ 0

De-esser Characteristic
Wideband Gain Reduction

De-esser Frequency Range
800Hz to 10kHz High Pass

12dB/octave

De-esser Release Time
12dB/octave Program-Dependent; approximately 1mS/dB

Enhancer HF Detail Characteristic
Program-controlled shelving equalizer

approximately 15dB maximum HF boost

Enhancer LF Detail Characteristic
Bell-shaped boost @ 80Hz

bell-shaped cut @250Hz

ratio is approximately 2:1

Expander/Gate Threshold Range
OFF to +15dBu

Expander/Gate Ratio
Adjustable 1.5:1 to 10:1

Expander/Gate Max Depth
>50dB

Expander/Gate Attack Time
Program-Dependent

approximately 2mS (at maximum attenuation)

Expander/Gate Release Time
Program-Dependent

approxiamtely 10mS/dB

Expander/Gate Dynamic Range
Typically 105dB

Power Consumption
15W

Operating Voltage
DO: 120VAC 60Hz

100VAC 50/60Hz; EU: 230VAC 50/60Hz

Operating Temperature
0°C to 45°C (32°F to 113°F)

Dimensions
1.75" x 5.75" x 19" (4.5cm x 14.6cm x 48.5cm)

Unit Weight
4.5 lbs/2.04 Kgs

Shipping Weight
6.54 lbs/2.97 Kgs
