LBA TGR-65
$ 69,156.90

Inovonics JUSTIN 808
$ 4,323.59 Original price was: $ 4,323.59.$ 4,118.78Current price is: $ 4,118.78.
TEM Opera Plus 10W
10 Watt FM Broadcast Transmitter
The TEM Opera Plus 10W FM broadcast transmitters are perfectly suited for low power radio stations, cable TV FM modulators and real estate advertising.
$ 2,514.51 Original price was: $ 2,514.51.$ 1,735.12Current price is: $ 1,735.12.
SKU:
102212
Brand:
TEM
TEM Opera Plus 10W
The technical solutions adopted by our engineers are focused to assure energy saving (among the lowest) and high reliability. Settings, protections, telemetry are totally microprocessor controlled. The installation and the maintenance of the equipment are respectively very fast and easy. These fully protected transmitters are indicated for use in unmanned stations.
FEATURES
- ECO LINE – HIGH EFFICIENCY TRANSMITTER
- Wideband circuits amplifiers with LDMOS technology
- Built-in exciter with digital frequency synthesiser
- Digital Stereo encoder, RDS encoder, AES-EBU input board (options)
- Audio change-over built-in
- Automatic fold-back ROS protection
- Fold-back temperature protection
- LCD to check all operating parameters
- 10W amplifiers
- Switching-mode Power Supply – Efficiency >95%
- Sealed duct cooling air with blowers
- Easy removable blowers
- Harmonics filter & directional coupler built-in
- GSM Telemetry & TCP/IP Webserver with SNMP/SMTP (option)
- Headphone jack on front panel
TECHNICAL SPECIFICATIONS
- Operating Voltage: 100V ÷ 260V AC
- Cooling system: forced air
- Operational Temperature Range: -5° to +50 °C
- Storage Temperature Range: -20° to +60 °C
- RF Output connector: N
- Operating temperature: da -5 °C, to +45 °C
- Storage temperature: da -10° a +55 °C
- Output connector RF: N
- RF Monitor connector: BNC
- Dimension: 485×44,4×625 mm
- Weight: 5 kg
