AudioScience Iyo-Dante 16.0MD 16-Input DB25 Interface

AudioScience Iyo-Dante 16.0MD is a 16-input Dante interface with AES59-standard DB25 mic/line connections, 32-bit A/D conversion, individual phantom power, AES67 interoperability and browser-based gain control.

AudioScience Iyo-Dante 16.0MD – 16-Input DB25 Interface converts sixteen balanced microphone or line-level sources into Dante network audio. DB25 connections follow the AES59-2012 wiring standard, supporting compatible analogue audio snakes. This input-only interface occupies 1U in a standard 19-inch rack and has no analogue outputs.

Sixteen Balanced Microphone/Line Inputs

The inputs accommodate levels from −60 to +24 dBu in 1 dBu steps, with a 10-kilohm input impedance. Select DB25 breakout cables with the correct pinout, length and source-end connectors. The interface uses 32-bit oversampling A/D conversion, with published sample rates of 44.1, 48 and 96 kHz.

Individual Phantom-Power Control

AudioScience Iyo-Dante 16.0MD provides individually switchable 48 V phantom power for compatible microphones. The maximum is 10 mA per channel, subject to an 80 mA total across sixteen inputs. Phantom power requires input gain above 24 dB. Check microphone current requirements and the complete channel configuration before deployment.

Dante Routing and Browser-Based Monitoring

Each physical input becomes a Dante transmit channel available for routing through Dante Controller. The embedded web interface provides gain adjustment, phantom-power switching, input muting and metering. Front-panel RGB LEDs display channel levels and streaming status, with separate indicators for synchronisation, system operation and power. AES67 mode supports compatible network integrations.

Network and Power Flexibility

Two Ethernet ports support redundant Dante connections or switched operation. The internal universal supply accepts 90–260 V AC at 47–63 Hz. An optional external 12 V DC supply provides an independent power path. AC and DC may operate separately or together for failover redundancy.

Basic Specifications

  • Factory model: Iyo Dante 16.0MD.
  • Analogue inputs: sixteen balanced microphone/line channels.
  • Analogue outputs: none.
  • Audio connections: AES59-2012 DB25.
  • Input-level range: −60 to +24 dBu.
  • A/D conversion: 32-bit oversampling.
  • Published sample rates: 44.1, 48 and 96 kHz.
  • Network: dual 100/1000 Mb/s Ethernet.
  • Protocols: Dante with AES67 interoperability.
  • Power: internal AC and optional external 12 V DC.
  • Dimensions: 482 × 152 × 44 mm.
