Altronic 77000 Series Coaxial Load – Precision Dissipation for Enhanced Performance
1. Purpose and Application of Equipment: The Altronic 77000 Series Coaxial Load is meticulously engineered to safely dissipate electrical energy, reaching its maximum rated value across the frequency spectrum of 540 to 1750 kHz. Designed for optimal performance, this load excels in diverse applications.
2. Equipment Supplied: Supplied with standard RF connectors, the 77000 Series includes EIA swivel flange, Unflanged flush, and Unflanged recessed connector types. Refer to the table below for flange selection based on load size:
Flange Selection:
| Load Size | 3 1/8″ | 4 1/16” | 6 1/8” | 9 3/16” |
|---|---|---|---|---|
| 7775 | √ | √ | √ | |
| 77100 | √ | √ | √ | |
| 77150 | √ | √ | √ | |
| 77200 | √ | √ | √ | |
| 77300 | √ | √ | √ | |
| 77450 | √ | √ | √ | |
| 77600 | √ | √ | √ | |
| 77900 | √ | √ | ||
| 771200 | √ | |||
| 771500 | √ |
Fig. 2 Load Size and Flange Selection
Standard Power Supply Voltages: After the Model #, select the appropriate power supply voltage designator:
-115: 110-120VAC, single-phase, 60 Hz -230: 208-230VAC, single-phase, 50/60 Hz -230: 208-230VAC, three-phase, 50/60 Hz -460: 415-480VAC, three-phase, 50/60 Hz
The Altronic 77000 Series Coaxial Load ensures precision dissipation, making it an ideal choice for a broad range of applications. For further details or inquiries, feel free to contact us.
