Technical Specification For RB-DA6

Audio Specification

Maximum Input Level:
+28dBu

Maximum Output Level:
+28dBu

Frequency Response:
20Hz to 20kHz ±0.1dB (600Ω load

ref 1kHz)

Gain Range:
Adjustable 8dB loss to 18dB gain (L & R adjust)

Common Mode Rejection:
>66dB typically

Input impedance:
>20kΩ bridging

Output impedance:
<50Ω

Distortion:
0.01% THD @ 1kHz

ref +8dBu output

Noise:
-100dB unity gain

ref +8dBu output

Connections

Inputs:
2 x XLR 3 pin female (balanced

can be unbalanced)

Outputs:
12 x XLR 3 pin male (balanced

can be unbalanced)

Mains Input:
Filtered IEC

switchable 110-120V

or 220-240V

fused

6W max

Fuse Rating:
Anti-surge fuse 100mA 20 x 5mm (230VAC)
Anti-surge fuse 250mA 20 x 5mm (115VAC)

Equipment Type

RB-DA6:
6 way stereo distribution amplifier

Physical Specification

Dimensions (Raw):
48cm (W) x 10.8cm (D) x 4.2cm (H) (1U)
19” (W) x 4.3” (D) x 1.7” (H) (1U)

Dimensions (Boxed):
58.5cm (W) x 22.5cm (D) x 7cm (H)
23” (W) x 8.9” (D) x 2.8” (H)

Weight:
Nett: 1.3kg  Gross: 1.9kg
Nett: 2.9lbs Gross: 4.2lbs
