CDsection

Type:
Single-mechanism compact disc player

Audio channel:
2 channel stereo

Quantization:
16-bit Linear

Sampling frequency:
44.1kHz at Normal Pitch

Oversampling ratio:
8 times

Frequency response:
20 to 20

000 Hz

Total harmonic distortion:
0.007%

Signal–to–noise ratio:
107dB

Dynamic range:
98dB

Channel separation:
90dB

Analog output:
RCA jacks

Output level:
2.0V at 0dB disc

Load impedance:
10kΩ or more

Digital output:
RCA jack

Signal format:
SPDIF or IEC-958 type II

Variable pitch control:
+16% maximum

Frame search accuracy:
1/75 second

Discs:
Standard compact discs (12cm and 8cm)

AUX section

Stereo mini jack:
Unbalanced jack

Reference input level:
–16dBV

Maximum input level:
0dBV

Input impedance:
22kΩ

Headphone

Output
Stereo

Output level:
20mW

Load impedance:
32Ω

General

Power supply:
120V AC +10%

60 Hz (U.S.A. and Canada models) 230V AC +10%

50/60 Hz (EU

U.K.

and Asia/Pacific models)

Power consumption:
15W

Environmental Conditions

Operational temperature:
5 to 35°C (41 to 95°F)

Operational humidity:
25 to 85% (no condensation)
