Standards
European RDS CENELEC; United States RBDS NRSC
Error Correction & Counting
Yes
AF Decoding
Yes
CT (Time/Date)
Yes
PI
,
PTY
,
DI
,
MS
Yes
TA/TP
Yes
RT (Radio Text)
,
RT+
Yes
PS (Program Service name)
Yes
ODA
Yes
Group Analyzer
Yes
BER Analyzer
Yes
Group Sequence Display
Yes
RDS RAW Data Display
Yes
Metering Accuracy
RF Level
±1 dB
,
0 to 100 dBµV
Total
,
Pos
,
Neg
±2 kHz
,
10 to 100 kHz
,
1 kHz resolution
Pilot
,
RDS
±0.5 kHz
,
1 to 12 kHz
,
0.2 kHz resolution
Audio
±1 dB
,
+10.0 to -55.0 dB
,
0.1 dB resolution
Outputs
Composite
3.5 Vp-p @ 75kHz
,
75Ω
,
unbalanced BNC Connector
Audio (L
,
R)
+12 dBm
,
600Ω balanced XLR Connector
AES3 (L
,
R)
5.0 Vp-p
,
110Ω
,
balanced XLR Connector
SPDIF (L
,
R)
3.0 Vp-p
,
110Ω
,
unbalanced BNC Connector
Optical (L
,
R)
Transmitter
,
TOSLINK
Alarms
Programmable terminals on rear panel
,
optoisolated
Headphone
6.3mm (1/4") Phone Jack
Communication Interfaces
USB
B-type Connector
Ethernet 10/100 Base-T
RJ45 Connector
GSM Modem
15 pin Male D-Sub Connector
Measurement Storage
Storage
2GB Build-in Memory Card
Data format
Text
,
CSV
Power
Voltage
100-240V / 50-60 Hz / 25W
Connector
IEC320
Size and Weight
Dimensions (W x H x D)
485 x 44 x 180 mm
Shipping Weight
3 kg
features
DSP-based IF Bandwide Filter
,
MPX & RDS Regeneration
Sophisticated DSP based Digital FM Tuner
Dual antenna ports with built-in RF attenuator
Up to 100 dBµV direct RF Antenna Input
Selectable wide range IF filter bandwidths
FM Band 87.1 – 108.1 MHz Basic Spectrum Analyzer
Advanced SNMP Ver.2C support
Fully DSP-based management core
Wide angle
,
easy to read OLED display
Very Intuitive Navigational Menu
Selectable De-emphasis – Off
,
50µs and 75µs
Built-in high performance Stereo Decoder
Real Time Audio Program Streaming
Remote Listening via optional GSM modem
Easy to use WEB interface
Apple and Android devices support
SNTP for automatic sync of the built-in clock
RDS and RBDS decoder with BER meter
Alarm dispatch via E-mail
,
SMS
,
SNMP and GPO
Complete status reporting with SMS via optional GSM modem
Protected access to the device settings
Balanced Analog Audio Outputs on XLR Connectors
Professional AES/EBU
,
SPDIF and Optical Digital audio outputs
LAN port for full TCP/IP remote control and monitoring
Adjustable MIN/MAX alarms for RF
,
Pilot
,
L & R Audio Levels
Adjustable MIN/MAX alarms for MPX & RDS
USB communication interface for local connectivity
Headphone output with front panel level control
Easy and intuitive Windows Application
Firmware updates will ensure improved operation
Accurate front-panel metering for local use
Restore Factory Parameters option
Wide operating voltage range: 100-240V AC
19" Professional Case for high RF immunity
Easy Installation and Setup
Chassis Dimensions
1U x 19" x 7"; 44 x 485 x 178mm
Shipping Weight
2kg
Power Supply
Internal 100 – 240V; 50 – 60Hz
Pilot/MPX Input
Yes
MPX/RDS Output
0 to 4095 mV
Inputs/Outputs
2 x GPI
,
4x GPO user-defined functionality
Communication Port
2xRS232
,
USB
,
LAN
Synchronization
External (Pilot or MPX) / Internal / Auto
Synchronization Monitoring
Yes
RDS Level adjustment
Digitally controlled
Phase adjustment
Yes
,
0 ÷ 359.9°
Separate outputs for RDS+MPX and for RDS only
Yes
Command to activate the RDS SCA
Yes
Side Chain Mode
,
Loop through mode
,
Bypass feature
Yes
RDS Subcarrier
100% Digitally Generated Shape / Bypass: 0 dB
Pilot synchronization
Input Level: -50dBu to +12dBu / Frequency: 19kHz
,
±3Hz
EN50067 compliant
Yes
Accurate Clock Time (CT) Sync with Internet Connection
Yes
Remote TA actuation for Traffic Announcements
Yes
GPS module for automatic synchronization of the built-in clock
Yes
Fully independent RDS decoder for self-monitoring purposes
Yes
Firmware can be upgraded in the field
Yes
Front-panel LCD displays all programmed data
Yes
Data may be entered on-site with Front-panel Buttons
Yes
Operating Temperature
0°C ÷ 55°C
RDS Features
Group supported
All
Group Sequence
Configurable
PS
6 DSN x 4 PSN
PI
6 DSN x 4 PSN
PTY
RDS/RBDS
AF Method A
25
AF Method B
up to 100
RT
Yes
,
10 messages
RT rate adjustment
Group Sequence
RT+ for songs and content tagging
Yes
TP
Yes
TA Control
Command
,
Contact closure
,
Software
PTYN
Yes
EON
4 PSN
CT
Yes
TMC
,
EWS
,
IH
,
TDC
Yes
Free Format Groups (FFG)
Yes
Open Data Application (ODA)
Yes
64-character Dynamic PS shown on all RDS/RBDS Radios
Yes
Auto "parses" long messages for best text display
Yes
Scrolling by character
from 1 up to 8
Scrolling by word
,
Auto centering
,
Truncate long words
Yes
Communication
Communication Interfaces
2xRS232
,
USB
,
LAN
Connection with Automation Software
Yes
Network Connectivity
2 TCP ports; 2 UDP ports
Scheduler
Yes
Configuration
Embeded Web Server
,
SmartGen Manager
Password Protection
Yes
ASCII Protocol
Yes
UDP
,
TCP
,
HTTP
,
SNTP
Yes
Alert notifications on user-defined events via SNMP traps or E-mails
Yes
Embedded SNMP agent permitting active management tasks
Yes
Custom HTML formatted E-mail templates with dynamic variables
Yes
Supported Network Protocols:
HTTP
,
FTP
,
SNMP
,
SNTP
,
SMTP
,
UPnP
,
UDP
,
TCP
UECP Protocol
Fully compliant with EBU SPB490 Ver.7.05
PI CALL Calculator
Yes
Remote Display
Yes
Supplied with Intuitive Software
Yes
Comes with 2-years Limited Warranty
Yes
features
Highly customizable
,
UECP compatible RDS Encoder
Fully Digital Synthesis of RDS signal with excellent quality and spectral purity
Fully independent RDS decoder for self-monitoring purposes
Front panel LCD Display and Buttons for operating without a computer
Remote configuration via ASCII or UECP protocols through RS232
,
LAN
,
USB
Supported Network Protocols: HTTP
,
FTP
,
TELNET
,
SNMP
,
SMTP
,
UpNP
,
UDP and TCP
4 x user-defined GPO
,
allowing easy management of external devices when needed
2 x General Purpose Inputs with user-defined functionality
Includes the TA function for traffic message priority override
Alert notifications on user-defined events via SNMP traps or E-mails
Real time clock Schedules for Scrolling Text and text lists
Custom HTML formatted E-mail templates with dynamic variables
SNTP & GPS module for automatic synchronization of the built-in clock
Supports European CENELEC and United States NRSC standards
Attractive price and very good price-performance ratio
Full support of Open Data Applications
Supports RT+ for songs and content tagging
PS & Radio Text Scrolling Options
Supports TMC (Traffic Message Channel)
Compatible with EWS (Emergency Warning System)
Embedded WEB server for interactive supervision
Fully compatible with UECP EBU SPB490 Version 7.05
MPX Loopthrough & Sidechain Modes
Internal or external Pilot / MPX synchronization
Very Intuitive UECP Configuration Software
Remote RDS viewer to visualize broadcasted data
Proved and reliable hardware for 24/7/365 operating
Easy Installation and Setup
LAN
,
USB & 2 x RS-232 Interfaces
Embedded SNMP agent permitting active management tasks
Interfaces with all popular radio automation systems
Built-in dedicated 19kHz source for internal sync
Built-in failsafe bypass relay
Separate outputs for RDS+MPX and for RDS only
Works with any FM exciter and stereo generator
Internal data diagnostics and transmission safeguards
19" Professional Case for high RF immunity
