Digigram IQOYA SERV/LINK 88 TC Multichannel IP Audio Codec 1U

Product Overview

The Digigram IQOYA SERVLINK 88 TC is a compact 1U multichannel IP audio codec designed for broadcasters who need several audio circuits in a single frame. It provides eight mono IP codec instances and flexible audio connectivity options, making it ideal for multiple STL or SSL links, feeding several web radios, or aggregating contribution feeds at a central site. Built on the proven SERV/LINK platform, it combines high channel density, low power consumption and extensive redundancy features in one manageable device.

Key Features

• 1U multichannel codec with eight mono IP audio codec channels for distribution and contribution links.
• Available with different audio I/O options, including analog, AES/EBU, MADI or AES67/Dante variants.
• Simultaneous encode, decode and transcode of multiple IP audio streams in various formats.
• Support for PCM, MPEG Layer II/III, AAC family, Opus, G.711 and G.722 codecs.
• Dual hot-swappable redundant PSUs and two Gigabit Ethernet ports for WAN audio and control.
• Fluid-IP, FEC and dual-port stream redundancy for resilient audio over unmanaged networks.
• Embedded web interface, SNMP and web services API for configuration, monitoring and alarms.

Typical Applications

IQOYA SERVLINK 88 TC suits regional networks that must transport several programmes between studios and transmitter sites, deliver multiple web radio streams to CDNs, or manage intercom and commentary circuits. With up to three decoding priorities per output, it can automatically switch between IP streams, local playlists and live inputs to keep audio on-air during failures.
