Furman PL-PLUS CE

Furman PL-PLUS CE 10A Power Conditioner with Lights and Voltmeter, 220V-240V Export

Elevate your audio and video performance while safeguarding your valuable equipment with the Furman PL-PLUS CE from the Classic Series. This rack-mountable power conditioner seamlessly integrates superior protection features with cutting-edge technologies for an unparalleled transient voltage surge suppressor.

Key Features:

1. Surge Protection with SMP Technology:
   • Furman’s exclusive Series Multi-Stage Protection (SMP) technology ensures the highest level of surge and spike protection available.
2. Noise Filtration with LiFT:
   • Linear Filtering Technology (LiFT) guarantees AC power filtering, delivering pristine power for unmatched audio and video clarity.
3. Voltage Protection with EVS Circuitry:
   • Advanced Extreme Voltage Shutdown (EVS) circuitry detects hazardous voltage irregularities, initiating a safe power down of the unit and connected equipment.
4. Pull-out Lights:
   • Dual smooth track retractable LED lights provide seamless illumination for your rack equipment, ensuring visibility in any environment.
5. Diagnostic Lights:
   • LED status indicators warn you of voltage anomalies or compromised protection, keeping you informed and in control.
6. LED Voltmeter:
   • A segmented LED voltmeter monitors and displays incoming line voltage, offering real-time voltage status at a glance.
7. Isolated Banks:
   • Isolated outlet banks minimize interference and noise contamination between components, optimizing overall performance.
8. 10 AMP Rating:
   • With a 10 Amp rating and a high inrush magnetic circuit breaker, the PL-PLUS CE ensures added protection against power fluctuations.
9. 11 Total Outlets:
   • Enjoy versatile connectivity with 11 total outlets, comprising 10 rear panel outlets and one front panel convenience outlet.
10. BNC Lamp Connector:

• The rear panel BNC connector powers any standard gooseneck lamp for rear rack illumination (lamp not included).

Specifications:

• Current Rating: 10 amps
• Operating Voltage: 180 to 274 VAC
• Over Voltage Shutdown: 275 VAC typically
• Spike Protection Modes: Line to neutral, zero ground leakage
• Spike Clamping Voltage: 376 VAC peak @ 3,000 Amps, 266 VAC RMS
• Response Time: 1 nanosecond
• Maximum Surge Current: 6,500 amps
• Noise Attenuation: 10 dB @ 10 kHz, 40 dB @ 100 kHz, 50 dB @ 500 kHz (Linear attenuation curve from 0.05 – 100 Ohms line impedance)
• Dimensions: 44.45mm H x 482.6mm W x 266.7mm D
• Weight: 5 kg
• Construction: Steel chassis, 3mm brushed and black anodized aluminum front panel; glass epoxy printed circuit boards
• Power Consumption: 25 VA
• Safety Agency Listing: CE

The Furman PL-PLUS CE is a testament to the marriage of advanced protection features and unparalleled performance, providing a robust power solution for professionals in the audio and video industry.
