Furman P-1400 AR E

Description

Furman P-1400 AR E

The Furman P-1400 AR E 6A Prestige Voltage Regulator is a sophisticated power management device designed to provide stable and clean AC power to protect sensitive electronic equipment. Here are some key features and specifications:

Features:

1. Voltage Regulation:
   • Delivers a stable 230 volts of AC power (switchable to 240V) with True RMS Voltage Regulation.
   • Accepts input voltage from 188V to 270V and maintains a constant output within ±10V.
2. Power Conditioning:
   • Equipped with Furman’s Linear Filtering Technology (LiFT) for AC power filtering, reducing line noise and ensuring optimal performance.
3. Protection Technologies:
   • Series Multi-Stage Protection (SMP) technology for surge and spike protection.
   • Extreme Voltage Shutdown (EVS) for detecting and safely powering down in unsafe voltage conditions.
4. Diagnostic Lights:
   • LED status indicators provide warnings when voltage is outside the nominal range or when protection has been compromised.
5. USB Charger:
   • Front panel USB outlets for charging media devices or powering USB lamps.
6. Voltmeter / Ammeter:
   • Large digital display with discrete dimmer button for monitoring line voltage and true RMS current draw.
7. Isolated Banks:
   • Isolated outlet banks to minimize inter-component interference and noise contamination.
8. 6 Amp Rating:
   • Features a 6 Amp rating with a high inrush magnetic circuit breaker for added protection.
9. Outlet Configuration:
   • 11 total outlets (10 rear panel outlets and one front panel convenience outlet).
10. BNC Lamp Connector:
    • Rear panel BNC connector for powering a standard gooseneck lamp for rear rack illumination.

Specifications:

• Maximum Output Current:
  • 6 amps @ 230 volts (230V output setting – 240V @ 240V output setting)
• Line Cord:
  • Detachable 2.5-meter black cord with Schuko plug (standard)
• BNC Socket for Rack Lamp:
  • 12VAC 500mA max (lamp not included)
• Regulation Range:
  • 182 to 262 VAC (230V output setting), 188 to 270 VAC (240V output setting)
• Over Voltage Shutdown:
  • 275 VAC nominal
• Spike Protection Modes:
  • Line to neutral, zero ground leakage
• Spike Clamping Voltage:
  • 376 VAC peak @ 3,000 amps
• Response Time:
  • 1 nanosecond
• Maximum Surge Current:
  • 6,500 AMPS
• Noise Attenuation:
  • 10 dB @ 10kHz, 40 dB @ 100kHz, 50 dB @ 500kHz
• Dimensions:
  • 19” W x 12.0” D x 1.745” H
• Weight:
  • 9.5 kg.
• Power Consumption:
  • (No load) 5 Watts

This device is suitable for audio and video applications where clean, regulated power is essential for optimal performance and protection of sensitive equipment.
