Barix Exstreamer 500

Name: Barix Exstreamer 500
SKU: 100758
Price: 625.00 EUR
Availability: InStock

Network Audio Encoder / Decoder

The Barix Exstreamer 500 INTL network intercom and PA component for commercial, industrial and security applications.

SKU: 100758

€625.00

Description

Barix Exstreamer 500

Barix Exstreamer 500 Encoder / Decoder is an interface that bridges audio to Ethernet to allow people to communicate with each other and to inform others.
You could call it an IP intercom and IP paging system.

Transmits voice, pre-recorded announcements, alarm messages and music over the network to any specific location
Two way communication is possible just like an ordinary intercom
Communicates over a standard network connection (10/100 Mbit/s) and supports TCP/IP-Protocol
Incorporates an integrated Web server for control and configuration
Works in combination with other Barix Annuncicoms as an autonomous IP Intercom, IP Paging system or can be used by itself with a PC controlled solution

Applications

IP paging, IPintercom and IP alarm system
Commercial IP audio distribution
Residential IP audio distribution

Related Products

Label Italy AKS/1N

In stock

€250.00

Select options

Weight	4 kg
features	Broadband, no-tune design 2 dB gain over a half wave High-power handling Anodised alloy construction DC short for lightning protection Collapsable in size for easier shipping
specification	Specifications Antenna type Dipole antenna Frequency range 87.5-108 MHz MAX power handling 800 Watts(each) 2kW with 7/16 conn. Impedance 50 ohms Gain (1xAKS/1N) 2dBd Gain (2 x AKS/1N) 5dBd VSWR better than 1.3:1 (88-108MHz) Freq. range 88-108 MHz (no tune) Connector N & 7/16 Dimensions 1400mm x 850mm x 60mm Weight 4.5kg
Ship Separately	0
Product can be split into multiple boxes	0

Digigram LoLa881

In stock

€1,100.00

Select options

Weight	0.5 kg
Dimensions	30 × 15 × 10 cm
Product can be split into multiple boxes	0
Ship Separately	0
specification	Short-length PCI Express x1 format 4 AES/EBU inputs / 4 AES/EBU outputs Optional High quality Sample Rate Converters (SRC) on all inputs: ratio 1:16 to 16:1, from 20 KHz to 216 KHz Sample rates from 32 KHz up to 192 KHz Synchronization: AES inputs, AES clock, word clock I/O, video sync Superior frequency synthesis and clock jitter reduction through audio-specialized components Supported sample formats: 16 bits, 24 bits, 32 bits, 32 bits float Windows low latency drivers: DirectSound, ASIO and ALSA Optional breakout box

TEM Opera plus 2kW

In stock

€6,270.00

Select options

Weight	35 kg
Dimensions	74 × 62 × 40 cm
Product can be split into multiple boxes	0
video	0
Ship Separately	0
specification	General Specification Operating voltage 230VAC ±15% min Cooling Forced Air Line power < 2800VA Operational temperature range -5° to 50°C Storage temperature range -20° to 60°C Output RF connector 7/16” Monitor RF connector BNC Dimensions 485×133, 2x625mm Weight 16 kg Radio Frequency Frequency range 87.5 to 108MHz Frequency setting in 10KHz or 100 KHz steps Setting mode By keys on the front panel/Remote Frequency stability < ±500Hz/year Frequency generation PLL synthesizer Modulation type direct VCO frequency modul. F3 Nominal frequency deviation ±75KHz Deviation linearity in all freq. range ±5KHz RF output power 2000 W ± 1 d B Harmonics emission <-70dBc Spurious emission <-95dBc Modulation Capability MONO (left and right) 30Hz to 15KHz STEREO (L-R & AES-EBU) 30Hz to 53KHz SCA + RDS 30Hz to 100KHz Composite Mono or Stereo + SCA + RDS MPX Characteristics Signal input MPX Composite Input impedance 10Kohm unbalanced Input connector BNC Input level Adjustable (Front/Remote) Audio freq. response (30Hz to 60KHz) < 0, 5 dB Modulation distortion <0.2% Signal to noise ratio >75dB Stereo Characteristics Signal inputs Left or Right – AES-EBU Input impedance 600ohm (bal.) or 10k ohm Input connectors Canon XLR Unbalance rejection >40dB Input leve Adjustable (Front/Remote) Pre-emphasis 75 or 50uS Audio frequency response (30Hz to 15KHz) <0.25dB Audio frequency response (19KHz to 100KHz) >50dB Cross-talk between left and right channel >50dB Distortion at frequency deviation of 75KHz <0.1% Signal to noise referred at deviation of 75KHz >75dB Suppression of 38KHz >50dB Spurious suppression outside band in according to ETS 300-384
features	ECO LINE – HIGH EFFICIENCY TRANSMITTER Wideband circuits amplifiers with LD-Mos technology Built-in exciter with digital frequency synthesiser Stereo encoder, RDS, AES-ABU and Audio change-over built-in Automatic fold-back ROS protection Fold-back temperature protection LCD display to check all operating parameters 2x1250W amplifier in only one heat-sink for highest reliability Switching-mode Power Supply – Efficiency >95% Sealed duct cooling air with blowers Easy removable blowers Harmonics filter & directional coupler built-in 3 unit 19” standard rack GSM Telemetry & TCP/IP Webserver Headphone jack on front panel
Color	Black

Sielco EXC 1000GX

In stock

€3,695.00

Select options

Weight	13.5 kg
Dimensions	49.00 × 90.00 × 52.00 cm
Color	Black
specification	Technical Data: Frequency range from 87, 5 to 108 MHz FM modulation 75 KHz peak deviation (adjustable) Audio and Mpx input level from -3, 5 to +12, 5 dBm @ 75 KHz deviation Auxiliary input channel level SCA from -12, 5 to +3, 5 dBm @ 7, 5 KHz deviation RDS from -24 to -8 dBm @ 2 KHz deviation Modulation distortion 75 KHz deviation <0.05%, 0.02% typical S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical Audio channels frequency response 30÷15000 Hz ±0.1 dB Pre-emphasis time constant 25/50/75 μs selectable Rated RF output power 500W, 1000W, 1500W Transmitter tuning steps 10/100 KHz Output power ALC stability ±3% Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) RF output connector 7/16 Power supply Single phase 230 VAc ± 15% Three phase N.A. Total consumption at rated RF power <830W (EXC500GT), <2400W (EXC1500GT) Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing Dimensions (WxHxD) 483x88x585 mm Weight 12kg
Ship Separately	0
Product can be split into multiple boxes	0
video	0
