Barix Exstreamer 205

Introducing the Barix Exstreamer 205, an innovative IP Audio decoder equipped with S/PDIF and 2x25W amplified output, along with a microSD slot. This versatile device offers comprehensive support for Internet Radio (AACplus, MP3, Shoutcast, TCP streaming) and VoIP (SIP, RTP) codecs and protocols. As part of the Exstreamer 20x series, these devices excel in decoding IP Audio streams and seamlessly play out the received audio signal through a built-in amplifier to 8 Ohm speakers. With its compatibility with a multitude of protocols, encoding methods, and application-specific firmware, the Exstreamer 205 is a perfect fit for Broadcast, Internet Radio, and VoIP applications. Furthermore, its local analog input capability allows the Exstreamer 205 to serve as an IP-controlled, high-quality amplifier.

Technical Specifications:

1. Electrical:
   • Input Voltage: 24 VDC, 70 Watt max. on a 2.1mm barrel connector
   • 24 VDC Power supply (100-240 VAC) included
2. Ethernet:
   • 10/100Mbps auto-detect
   • RJ-45 connector with integrated Link/Activity LED
   • Protocols: TCP/IP, UDP, RTP, SIP, DHCP
3. Analog Output:
   • 2 x 25 W (RMS @ 8 Ohm) speaker outputs
   • 3.5 mm (1/8 inch) headphone jack
   • S/P DIF out (optical)
   • Output level software controllable
   • Frequency response (-3 dB): 19 Hz .. 20 kHz *
   • Dynamic range: 94 dB
   • SNR/THD: -94 dB, <0.05%)
4. Audio Formats:
   • MP3 CBR/VBR, up to 320 kbps, 8..48 kHz sample freq.
   • AAC-HE (AAC, AAC plus, AAC plus V2)
   • WMA (up to version 9)
   • Ogg Vorbis
   • PCM linear 16bit @8, 16, 22.05, 24, 32, 44.1, 48 kHz
   • G.711, uLaw, aLaw (sample rates same as PCM)
5. RS-232 Interface:
   • 300..230‘400 Baud asynchronous
   • For serial tunneling or local control
   • 12 VDC supply output for external devices (100 mA max.)
6. IR Interface:
   • Built-in IR receiver, IR remote control included
   • Optional external IR receiver via serial port (IR Kit)
7. Mechanical:
   • Aluminum case, 460g
   • Rack and wall mountable using accessories
   • Dimensions (W x H x D): 108 x 38 x 125 mm (4.25 x 1.5 x 4.92 inch)
8. Model Comparison:
   • Model 200: Speaker output 2 x 25 Watt on 8 Ohm, Memory USB
   • Model 205: Speaker output 2 x 25 Watt on 8 Ohm, Memory MicroSD, Line in
9. MTBF:
   • According MIL217F at 25°C
   • Exstreamer 200 min. 460,000 hours
   • Exstreamer 205 min. 410,000 hours

*Depends on used codec, best results @48kHz PCM

Elevate your audio experience with the Barix Exstreamer 205 – the pinnacle of precision, adaptability, and reliability in IP audio decoding and amplification.
