The AudioScience ASI8821 is a series of professional PCI Express tuner adapters primarily designed for AM/FM/RBDS/RDS radio broadcast audio monitoring and auditing purposes. These tuner adapters are equipped with features catering to various radio broadcasting needs and are recognized as an industry standard in radio monitoring installations worldwide.
Key features of the ASI8821 series include:
- Support for Multiple Radio Standards: The ASI8821 supports a range of radio standards including HD Radio, DAB, and DAB+.
- Modular Design: The adapters are based on tuner modules, with each module housing four tuners. The adapter can accommodate up to two modules, allowing for a maximum of eight tuners.
- Simultaneous Channel Reception: Users can receive and record up to eight different channels of AM or FM simultaneously from a single antenna input.
- Recording Formats: The ASI8821 supports various recording formats including PCM, MPEG-1 Layer 2, and MPEG-1 Layer 3 (MP3).
- Audio Monitoring: It enables simultaneous audio monitoring of all tuners.
- MRX™ Technology: This technology allows each stream to have an independent sample rate ranging from 8 to 48kHz.
- Compact Form Factor: The card comes in a short length PCI Express format (6.6 inches/168mm), making it suitable for various system configurations.
- Scalability: Users can install up to eight cards in one system for expanded capabilities.
- Driver Support: The ASI8821 is supported by both Windows and Linux software drivers, ensuring compatibility with different operating systems.
- Third-Party Software Compatibility: It is compatible with third-party logging software, providing flexibility in system integration.
Available Models of ASI8821:
- ASI8821-1000: 4 tuners for AM/FM/RBDS/RDS
- ASI8821-1100: 8 tuners for AM/FM/RBDS/RDS
- ASI8821-2000: 4 tuners for AM/FM/RBDS/RDS with MCX external antenna jacks
- ASI8821-2200: 8 tuners for AM/FM/RBDS/RDS with MCX external antenna jacks
- ASI8821-5000: 4 tuners for HD Radio/DAB/DAB+
- ASI8821-5500: 8 tuners for HD Radio/DAB/DAB+
These models offer various configurations to suit different broadcasting requirements. For more information or sales inquiries, interested parties are encouraged to contact the AudioScience sales team.
