Technical Specification For RB-SC1

Audio Specification

Dynamic Range:
120dB

Distortion and Noise:
-114dB THD + N at 1kHz

ref 0dB FS

Input Impedance:
75Ω S/PDIF inputs

110Ω AES/EBU input

50Ω BNC TTL word clock input

Sample Frequency Range:
Master rates of 32kHz

44.1kHz

48kHz or 96kHz

or can synchronise to incoming 32kHz to 100kHz sample rate

Bit Depth:
Up to and including 24 bit

Rear Panel Connections and Controls

Inputs:
2 x AES/EBU XLR 3 pin female (audio and sync)

2 x S/PDIF RCA phono (audio and sync)

1 x TTL BNC female (sync)

Outputs:
1 x AES/EBU XLR 3 pin male

1 x S/PDIF RCA phono

Input Select:
Push-button switch between AES/EBU and S/PDIF

Output Select:
Push-button switch between AES/EBU and S/PDIF

Sync Select:
Push-button switch between AES/EBU and S/PDIF

with DIP switch selection between TTL and the other two inputs.

Operational Modes:
Master mode

auto sync mode

auto lock mode and slave mode

set via rotary switch

Status Bits:
Forced to consumer mode

professional mode

or set to follow input with DIP switch selection.

Mains Input:
Filtered IEC

continuously rated 85-264VAC @ 47-63Hz

max 10W

Fuse Rating:
Anti-surge fuse 100mA 20 x 5mm (230VAC)

Anti-surge fuse 250mA 20 x 5mm (115VAC)

Equipment Type

RB-SC1:
Sample rate converter

Physical Specification

Dimensions (Raw):
28cm (W) x 10.8cm (D) x 4.2cm (H) (1U)

11” (W) x 4.3” (D) x 1.7” (H) (1U)

Dimensions (Boxed):
36cm (W) x 20.5cm (D) x 6cm (H)

14.2” (W) x 8” (D) x 2.4” (H)

Weight:
Nett: 1.0kg Gross: 1.4kg

Nett: 2.2lbs Gross: 3.1lbs
