The Sonifex PC-DAB radio capture card receives and decodes the entire contents of up to four DAB+/DAB ensembles, rendering each audio service as a virtual Windows audio capture device for use with multichannel recording or monitoring software.

Sonifex PC-DAB

In stock

Original price was: $ 2,067.63.Current price is: $ 1,964.82.
Select options
-6%
The Sonifex RB-DDA6A applications include distributing audio from a digital mixing desk to multiple digital recorders or feeding multiple studios with an output from a DAT machine.

Sonifex RB-DDA6A

In stock

Original price was: $ 719.67.Current price is: $ 679.69.
Add to Cart
Weight 1.4 kg
Dimensions 21 × 36 × 6 cm
-6%
The Sonifex RB-DDA6A3 digital distribution amplifier is used for distributing AES-3id digital audio, repeating both the audio data and the status information of the input whilst re-normalising to standard digital audio levels.

Sonifex RB-DDA6A3

In stock

Original price was: $ 719.67.Current price is: $ 679.69.
Add to Cart
Weight 1.4 kg
Dimensions 21 × 36 × 6 cm
-6%
The Sonifex RB-DDA6S digital distribution amplifier is similar to the RB-DDA6A except that it is used for distributing digital audio data in S/PDIF format.

Sonifex RB-DDA6S

In stock

Original price was: $ 719.67.Current price is: $ 679.69.
Add to Cart
Weight 1.4 kg
Dimensions 21 × 36 × 6 cm
-5%
The Sonifex RB-DA6G is a 1U rack-mount high performance 6-way stereo distribution amplifier for splitting a source into a number of different outputs.

Sonifex RB-DA6G

In stock

Original price was: $ 725.38.Current price is: $ 691.11.
Add to Cart
Weight 1.9 kg
Dimensions 23 × 59 × 7 cm
-5%
The Sonifex RB-HD6 headphone distribution amplifier is a 1U rack-mount which distributes stereo audio to up to 6 different sets of headphones, or can be used as 6 independent headphone amplifiers, each with their own input and volume control.

Sonifex RB-HD6

In stock

Original price was: $ 742.52.Current price is: $ 702.54.
Add to Cart
Weight 2 kg
Dimensions 23 × 59 × 7 cm
-5%
The Sonifex RB-MA2G consists of two independent low-noise microphone pre-amplifiers with front panel level controls and metering, for converting microphone level signals to line level, or for driving long lines from microphones to mixing equipment.

Sonifex RB-MA2G

In stock

Original price was: $ 742.52.Current price is: $ 702.54.
Add to Cart
Weight 2 kg
Dimensions 23 × 59 × 7 cm
-5%
The Sonifex AVN-DIO16 is a professional-grade Dante to XLR analogue output converter, designed to seamlessly integrate analogue audio systems into modern AoIP.

Sonifex AVN-DIO16

In stock

Original price was: $ 771.08.Current price is: $ 731.09.
Add to Cart
-5%
The Sonifex AVN-DIO14 is a Dante to XLR analogue stereo input & output converter in the Sonifex DIO range of Dante input/output devices.

Sonifex AVN-DIO14

In stock

Original price was: $ 782.50.Current price is: $ 742.52.
Add to Cart
-6%
The Sonifex RB-DA6P is a version of the RB-DA6 audio distribution amplifier which uses Neutrik Phoenix style connectors instead of XLR inputs and outputs.

Sonifex RB-DA6P

In stock

Original price was: $ 799.63.Current price is: $ 753.94.
Add to Cart
Weight 1.9 kg
Dimensions 23 × 59 × 7 cm
The Sonifex S2 is a modular broadcast mixer which offers digital audio quality with analogue reliability in a modular format.

Sonifex S2

In stock

Original price was: $ 8,516.11.Current price is: $ 8,110.58.
Select options
Weight 2 kg
features

Assigning an Input Channel to an Output Bus – Switches at the top of the channel are used to select the output group routing

,

to either Program

,

Audition

,

or both output busses. Selecting the PGM and/or AUD buttons routes the channel audio to the PGM and/or AUD mix busses. The buttons illuminate green to indicate the routing status.
Changing the Input Level – Coarse gain is set using pre-set potentiometers on the channel circuit board which allow unbalanced inputs to be used on mono and stereo line inputs. The front panel TRIM control allows fine gain of ±12dB.
Changing the Signal Pan

,

or Balance – The BAL/PAN control is used on mono channels to pan the mono input signal in the stereo image and on stereo channels to balance the stereo image.
CUE/PFL (Pre Fade Listen) – Selecting the CUE/PFL button routes the pre-fader input signal to the monitoring system where the signal can be heard via headphones and/or loudspeakers. The button lights green when CUE/PFL is active and a jumper option is available to cancel the CUE/PFL selection when the fader is raised. This button works with both a momentary and latched operation – if held down

,

the selection is cancelled on release

,

otherwise the button is alternate action.
Fader Start & ON Button Control – The ON button works in conjunction with the 100mm long-throw carbon fader and is used to control channel remotes (e.g. starting a CD player)

,

routing and timers

,

etc. When unlit

,

the channel is off. Flashing red indicates that the channel has been selected to ON but not routed to either PGM or AUD. Steady red indicates that the channel is ON and “armed”

,

ready for the fader to be raised. Raising the fader changes the illumination to green indicating that the channel is live. Alternatively

,

with the button unlit the fader may be raised and the channel can be operated simply by selecting ON. The illumination in this case toggles between unlit (channel OFF) and green (channel ON).
Programmable Button Settings – To make the S2 modules as flexible as possible

,

every button on each channel can be set to a number of different modes to aid the use of the mixer and allow for extra functionality. Each button can be set to either operate manually

,

be permanently on

,

or permanently disabled. Also

,

the ON button can be configured to operate in a number of modes

,

altering remote start functions

,

and the channel ON function can be controlled remotely by automation playout systems

,

such as RCS® or VCS.
Scribble Pad – A scribble pad is provided at the bottom of the channel for user labelling of the channel function.
specification

Technical Specification For S2

Input/Output Impedances

Mic Input:
> 1k5Ω electronically balanced

Mono Line Input:
> 20kΩ electronically balanced

Stereo Line Input:
> 20kΩ electronically balanced

PGM & AUD Output:
< 75Ω electronically balanced

Mono Output:
< 75Ω electronically balanced

Monitor Outputs:
< 75Ω unbalanced

AES Input/Output:
110Ω

S/PDIF Input/Output:
75Ω

BNC Wordclock input:
50Ω

Input/Output Gain Range

Mic Input:
Preset pot +13dB to +66dB ref -50dBu

,

TRIM pot ±12dB

Mono Line Input:
Preset pot -6dB to +10dB ref 0dBu

,

TRIM pot ±12dB

Stereo Line Input:
Preset pot -6dB to +10dB ref 0dBu

,

TRIM pot ±12dB

Telco Input:
Preset pot -6dB to +10dB ref 0dBu

,

TRIM pot ±12dB

Telco Output:
Preset pot -6dB to +4dB ref 0dBu

Mix Minus Input:
Preset pot -6dB to +10dB ref 0dBu

,

TRIM pot ±12dB

Mix Minus Output:
Preset pot -3dB to +3dB ref 0dBu

Digital Input:
0dBFS = +12dBu on input; TRIM pot ±12dB allowing 0dBu to +24dBu

Digital Output:
0dBFS = +18dBu

Frequency Response

Mic Input:
40Hz to 20kHz

,

-1dB

,

+0dB (-3dB at 130Hz with HPF in)

Line Inputs:
20Hz to 20kHz

,

– 0.5dB

,

+0dB

RIAA Input:
30Hz to 16kHz ±1.5dB RIAA equalised

Noise (20Hz to 20kHz)

Mic Input E.I.N.:
-129dB with 150Ω source

Stereo Inputs (fader down

,

no routing):
-89dB ref 0dB

Stereo Inputs (fader down

,

one channel routed):
-89dB

Stereo Inputs (unity gain

,

no routing):
-89dB

Stereo Inputs (unity gain

,

one channel routed):
-86dB

Stereo Inputs (unity gain

,

two channels routed):
-83dB

Distortion

Total Harmonic Distortion:
0.015% at 1kHz

,

0dB

0.025% at 10kHz

,

0dB

Crosstalk

Inter-channel:
< -90dBu

Stereo:
-90dBu at 1kHz

Equalisation

LF Shelving at 100Hz:
±7dB

HF Shelving at 6.5kHz:
±7dB

Range

Pan Range:
off/-3dB centre/off

Balance Range:
±6dB

Common Mode Rejection Ratio

Mic Input:
> 100dB at 70dB gain

Digital I/O

Sync Input Sample Rate:
30kHz – 100kHz

Output Sample Rates (Using Onboard Clock):
32kHz

,

44.1kHz

,

48kHz

,

& 96kHz

Output Sample Width:
16

,

20

,

24 bit (24 bit on V2 ODA/ODP)

Output

Headphone Output Load:
>45Ω

,

400Ω recommended

Maximum Output (Analogue):
+26dBu balanced into 2kΩ or greater

Power

Power (S2-PSU):
Filtered IEC

,

switchable 115V

,

230V

,

fused

,

210W max.

Dimensions (S2-PSU):
48cm (W) x 24.3cm (D) x 8.8cm (H)

(Raw):
19” (W) x 10” (D) x 3.5” (H)

Dimensions (S2-PSU):
51cm (W) x 41.5cm (D) x 17cm (H)

(Boxed):
20” (W) x 16.3” (D) x 6.7” (H)

Weight (S2-PSU):
Nett: 6kg Gross: 7.8kg

Nett: 13.2lbs Gross: 17lbs

Dimensions (S2-PSUS):
48cm (W) x 23cm (D) x 4.4cm (H)

(Raw):
19” (W) x 9” (D) x 1.7” (H)

Dimensions (S2-PSUS):
55cm (W) x 39.3cm (D) x 8.5cm (H)

(Boxed):
21.6” (W) x 15.5” (D) x 3.4” (H)

Weight (S2-PSUS):
Nett: 1.58kg Gross: 2kg

Nett: 3.5lbs Gross: 4.4lbs
Ship Separately

0
Product can be split into multiple boxes

0
-6%
The Sonifex RB-DA24MD is an audio distribution amplifier offering 2 inputs and 24 outputs in a 1U rack mount unit.

Sonifex RB-DA24MD

In stock

Original price was: $ 822.48.Current price is: $ 776.79.
Add to Cart
Weight 2.2 kg
Dimensions 28 × 59 × 11 cm
-6%
The Sonifex RB-PMX4 A dual balanced converter that allows the user to convert two independent stereo inputs to two fully buffered mono outputs.

Sonifex RB-PMX4

In stock

Original price was: $ 822.48.Current price is: $ 776.79.
Add to Cart
Weight 2.2 kg
Dimensions 23 × 59 × 7 cm
-6%
The Sonifex AVN-DIO12 is a sophisticated audio interface designed for integrating dual microphone inputs into a Dante® Audio-over-IP (AoIP) network.

Sonifex AVN-DIO12

In stock

Original price was: $ 822.48.Current price is: $ 776.79.
Add to Cart
Weight 0.7 kg
Dimensions 18 × 17 × 6 cm
-5%
The Sonifex AVN-DIO15 is a 4 analogue XLR input to Dante converter in the Sonifex DIO range of Dante input/output devices.

Sonifex AVN-DIO15

In stock

Original price was: $ 839.62.Current price is: $ 793.92.
Add to Cart
