Wisycom AGN00

Name: Wisycom AGN00 - Broadcasters Warehouse
SKU: 115377

Ground Plane Antenna

AGN00 is a groundplane, vertical-polarization omnidirectional antenna.

FEATURES

Broadband operations
– VHF (130 ÷ 250 MHz), switching-window = 25 MHz
– UHF (470 ÷ 880 MHz), switching-window = 80 MHz
Easy to mount thanks to the supplied plug
N-female connector
Vertical polarization
Omnidirectional radiation

Specifications

Frequency ranges	VHF (130 ÷ 250 MHz), switching-window = 25 MHz, UHF (470 ÷ 880 MHz), switching-window = 80 MHz
SWR	< 1:1.5; typ. = 1:1.4
Polarization	Vertical
Radiation	Omnidirectional
Connector	N type female
Impedance	50 Ω
Mounting	directly on a tripod stand or other support with standard 3/8” screw.
Dimensions	78 mm max. (diameter), 90 mm (L)
Weight	approx. 800 g
