Lucoro SMS Sentinel

Name: Buy Lucoro SMS Sentinel I Broadcasterswarehouse.com
SKU: 113037
Price: 65.00 EUR
Availability: InStock

SKU: 113037

€65.00

Description

Lucoro SMS Sentinel

This highly compact GSM device connects directly to our FMTX-series transmitters (check compatibility), and sends a text message to engineers or station owners to alert them of anomalies with their transmission system.

Simply program up to three cell phone numbers into the Sentinel using the free Windows(TM) software via its USB port, and then insert a Pay-as-you-Go SIM card.

The Sentinel will then continually monitor the transmitter status and send a text when forward power, reflected power, temperature, or audio silence issues are detected.

The engineer can then access the transmitter web interface for more detailed information and decide whether a visit to the transmitter location is necessary to remedy the cause.

With Quad Band compatibility, this easy to use device can be deployed simply and quickly and the contact numbers updated via USB at any time.

It can also be customised to suit other alarm sources (please enquire).

The Sentinel requires a 5V power source or AC power adapter capable of 2A peak current.

If the power outage function is required, as second ‘auxiliary’ 5V power source or AC power adapter, is required. The current requirement for this supply is less than 10mA.

Features

Very small dimensions
Easy plug-and-go installation
Quad band
GSM compatibility
SMS alerts to one or more cell phone numbers
LED status indicator

Applications

FMTX-series transmitter monitoring
Other system monitoring (custom options available)
Site monitoring (custom options available)

Specifications

Dimensions (main body): 40 H × 63 W × 30 D (mm)
Weight: 300 grams (approx)
Modes: GSM850, EGSM900, DCS1800, PCS1900. GPRS Multi-Slot Class 12
Frequencies: 880915MHz, 1710-1785MHz
Output power: GSM850, EGSM900 Class 4 (2W) DCS1800, PCS1900 Class 1 (1W)
Power: DC 5V 2400mA
SIM form factor: Micro SIM
