2WCOM A30

The All-In-One Monitoring receiver for FM/RDS, MPX and DAB+

2wcom carries on with its very successful FM / RDS Monitoring program for broadcasters.
The new A30 FM Monitoring Receiver Decoder monitors all-important “ON-AIR” FM and RDS parameters in your FM network. The double tuner concept allows you to monitor two different FM stations continuously or to control one station all the time and scan up to 30 different FM radio stations successively as well.

The important FM-RDS parameter of a station can be set up individually under the alarm settings. If a value does not comply with the pre-settings, an alarm can be forwarded via SNMP, e-mail or relay to a service centre. All the alarms can be stored in a log file. If necessary, you can generate a CSV file for further processing. All alarm activities are being stored with a time stamp, type of alert and the equivalent frequency in this file as a document for you.

Another option is the very precise MPX power and deviation measurement to avoid getting any penalties in your country derived from overshooting of the allowed MPX level.

All RDS data, like Group data, ODA, TA, RT, RT+, AF lists and TMC data can be displayed by using the RDS Lab Software.

ISD -Intelligent Silence Detection – offers security in transmission with its active and passive “loop-through” feature of the analogue L-R / AES and the MPX signal.
The A30 detects loss of the main source and switches over to a backup source automatically. After the signal is back on the main source, the former status will be restored again.

Listen to the audio from anywhere to every single FM station via mp3 live-streaming.

Additionally, the A30 can function as a backup Rebroadcast Receiver and as a
RDS-Databridge too. The embedded web server guarantees worldwide access remotely.

In case of any FM/RDS-Transmission problems, the A30 informs you first automatically before your audience does. It is just a good feeling to have an efficient and reliable FM-RDS Monitoring System available 24/7/365.
