Single (Hx1) or two-line (Hx2) capacity with standard analog I/O (1 each send and receive in/out for Hx1, 2 each for Hx2).
Convenient switchable mic/line input.
Available AES/EBU digital audio I/O option available at time of order, or as a field upgrade kit.
Our most advanced digital POTS hybrids ever, with DSP algorithms optimized for superior performance with today’s wide variety of incoming call types.
Font-panel send and receive audio metering.
Telos DDEQ (Digital Dynamic EQ) and adjustable smart-level AGC ensure spectrally consistent audio from call to call — even on notoriously tough cellular calls.
Excellent trans-hybrid loss of >55dB.
Smooth, proven, symmetrical wide-range AGC by the audio processing experts at Omnia Audio.
Studio adaptation and a subtle, inaudible pitch shifter to prevent feedback in open-speaker studio environments.
Precision adjustable caller override.
Analog I/O 24-bit A/D/A sample rate conversion, 20 dB headroom from +4 dBu nominal levels.
AES/EBU I/O sample rate converters accept 32, 44.1, and 48 KHz rates. Clock for outputs may be sourced from the AES inputs or internally-generated at 48 KHz.
Incredible dybanuc range of > 92 db (analog in to analog out, studio loop mode, 10 hz – 20 khz A-weighted)
Auto-Answer with selectable ring count and disconnect-signal detection.
Call screening and line-hold features.
Typically 0dBU for average line level
Off Hook Voltage:
2 Wire Connectors:
RJ11 socket – line
RJ11 socket – handset
Front Panel Operational Controls
Push button with indicator
Indicates incoming ringing
Indicates connection to the telephone line
Line powered telephone line listen unit
77mm (W) x 83mm (D) x 42mm (H)
3.0” (W) x 3.3” (D) x 1.7” (H)
Nett: 0.20kg Gross: 0.70kg
Nett: 0.50lbs Gross: 1.6lbs
Features of the CM-TLL
Audio interface to direct analogue exchange lines – receive calls with electrical isolation from the line.
Line powered, requiring no battery or external power.
LEDs indicating ‘Ring’ and ‘On Hold’ conditions.
Loop-through line sockets provide in-line connection with existing telephone.
Existing telephone remains connected when the unit is in use.
Line connections to British or International sockets via supplied cable kit.
Connection to the telephone set is maintained while the unit is in use.
Small, rugged extruded aluminium case with XLR3 male 4-wire connector.
